FRP Composite Doors




CF34 HEAVY DUTY TIGER COMPOSITE FRP FIBERGLASS DOOR

  • 1-3/4" thickness.

  • Doors are Seamless in design.

  • Face sheets are commercial quality 1/8" in thickness. Door faces and vertical edges are flush with no visible seams. Face sheets are totally supported by polyurethane adhesive.

  • Density of foam core exceeds 2 pcf and has a crush strength of 3600 psf.

  • Doors have a full lifetime warranty.

  • Hinge edges are mortised for 4-1/2' or 5" as specified.

  • High Density polyethylene blocking to be located at each hardware location, predrilled pilot holes.

  • Lock edge has a standard bevel and is prepared for specified hardware.

  • Closer reinforcement to be pultruded FRP blocking.

  • Finish: Doors are supplied with one coat of factory primer or two-part polyurethane enamel finish coating from a selection of standard colors or custom colors as specified.






FD25 Heavy Duty FRP Faced Door



  • 1-3/4″ Thick Door with fiberglass faces with aluminum structure framing.

  • Door constructed to meet heavy duty usage.

  • Built in 1/8″ thick x 6″ tubular closer reinforcing.

  • Extruded Tubular Aluminum Sub-Framing System.

  • Built in strength using true mortise and tennon corner.







FD55 Heavy Wall Wide Stile FRP Faced Door



  • 1-3/4″ Thick Door with fiberglass faces with aluminum structure framing.

  • Tubular Aluminum Extrusions.

  • Heavy Wall Wide Stile Internal Sub-Frame.

  • Internal 6″ Head Rail; 5″ Hinge and Lock Stiles.

  • Built in strength using true mortise and tennon corner joint assembly.

  • 3/8″ Thru Spline Tie Rod Assembly.







  • 1-3/4" Thick FRP Door

  • U. L. Fire Ratings 20 - 60 - 90

  • Standard All Doors 3/4" Stainless Steel Perimeter Edge Protection Covers

  • Exterior fire rated doors are not covered under a factory warranty.

  • Doors with vision lites require fire rated glass which can be supplied by glass or glazing supplier.

  • FRP Faced Fire Door Tech Sheet






Wg25 Embedded Woodgrain Faced Door



  • 1-3/4" Thick FRP faced door with an exceptional wood face appearance

  • A semi embedded wood grain version of doors with pebble embossed face sheets.

  • This fiberglass face sheet can receive a factory applied stain or paint while still allowing a wood grain to appear thru the finish.

  • The finish receives a factory applied clear U.V. protective coating.

  • FRP Woodgrain Door Tech Sheet




FLUSH ALUMINUM FACED DOORS




AD25 Standard Aluminum Faced Door

  • 1-3/4" Thick Door

  • Smooth Flush Aluminum Face Sheet

  • Optional Face Sheet Patterns

  • 1/8" Tempered Hardboard Backer





AD55 Heavy Wall Aluminum Faced Doors



  • 1-3/4" Thick Door

  • Smooth Flush Aluminum Face Sheet

  • Optional Face Sheet Patterns

  • 1/8" Tempered Hardboard Backer





STILE AND RAIL DOORS



SR25 Narrow Stile and Rail Door

  • 1-3/4" Thick Door.

  • 2-1/8" Narrow Stile Door Rails.

  • 4" Standard Top Rail.

  • 4" Standard Bottom Rail.

  • Optional Mid-Rails are available.




SR55 Wide Stile and Rail Door

  • 1-3/4" Thick Door.

  • 5" Wide Stile Door Rails.

  • 6-1/2" Standard Top Rail.

  • 6-1/2" Standard Bottom Rail.

  • Optional Mid-Rails are available.

  • Optional FRP Faced Mid-Panels are available.

  • Optional 10" ADA Bottom Rail.
